Adjusting the water temperature on a Globe Union tub shower can be a straightforward process once you understand the mechanism. Most Globe Union models feature a single-handle design that controls both water volume and temperature. To adjust the temperature, start by identifying the handle’s position: pulling it up typically increases the water flow, while turning it left or right adjusts the temperature. If the water is too hot or cold, you may need to remove the handle and adjust the temperature limit stop, a small screw or stopper inside the valve that restricts how far the handle can turn toward the hot side. Always refer to your specific model’s manual for detailed instructions, as designs can vary slightly. Proper adjustment ensures a comfortable and safe showering experience while preventing scalding or discomfort.
| Characteristics | Values |
|---|---|
| Model Compatibility | Globe Union tub shower models with a temperature limit stop mechanism |
| Tools Required | Phillips screwdriver, flathead screwdriver (if needed) |
| Adjustment Location | Behind the shower handle or faucet cover |
| Temperature Limit Stop | A screw or rotating mechanism to control maximum hot water temperature |
| Adjustment Direction | Counterclockwise to increase hot water, clockwise to decrease |
| Safety Feature | Prevents scalding by limiting maximum water temperature |
| Testing Method | Run water after adjustment to ensure desired temperature |
| Reassembly | Replace handle or cover after adjusting the limit stop |
| Common Issues | Limit stop screw may be stiff or require gentle force to turn |
| User Manual Reference | Check the Globe Union manual for model-specific instructions |
| Professional Assistance | Recommended if unsure or if the mechanism is difficult to adjust |
Explore related products
What You'll Learn
Locate Temperature Limit Stop
To locate the temperature limit stop on your Globe Union tub shower, you'll first need to understand its purpose. The temperature limit stop is a safety feature designed to prevent the water from becoming too hot, reducing the risk of scalding. It is typically set at the factory to limit the handle's rotation, thereby controlling the maximum hot water output. Before you begin, ensure the water supply is turned off to avoid any accidental spills or adjustments while working.
Start by identifying the type of handle your Globe Union tub shower has. Most models feature a single lever or a dual-control handle. For a single lever handle, you’ll need to remove the handle to access the limit stop. Begin by prying off the handle's cap or button, usually located at the center of the handle. Use a flathead screwdriver carefully to avoid damaging the finish. Once the cap is removed, you’ll see a screw holding the handle in place. Remove this screw and gently pull the handle away from the valve stem.
For dual-control handles, the process is slightly different. These handles often have a plastic or metal cover plate that needs to be removed first. Unscrew any visible screws holding the cover plate and lift it off. Beneath the plate, you’ll find the temperature limit stop, which is usually a small plastic or metal piece positioned on the valve cartridge. It may be secured with a screw or a clip, depending on the model.
Once the handle is removed, locate the temperature limit stop on the valve stem or cartridge. It is often a notched or grooved component that restricts the handle's movement. In some Globe Union models, the limit stop is adjustable by rotating it counterclockwise to allow more hot water or clockwise to restrict it further. Ensure you make small adjustments and test the water temperature after each change to avoid setting it too high.
If the limit stop is not adjustable, you may need to replace it with a different one to achieve your desired temperature range. Globe Union typically provides replacement stops with varying temperature settings. Refer to your model's manual or contact the manufacturer for the correct replacement part. After adjusting or replacing the limit stop, reassemble the handle and test the water temperature to ensure it meets your needs. Always exercise caution and follow safety guidelines when working with plumbing fixtures.
Efficient RV Showering: How Many Gallons of Water Do You Need?
You may want to see also
Explore related products
Adjust Rotary Temperature Control
Adjusting the rotary temperature control on a Globe Union tub shower is a straightforward process that allows you to fine-tune the water temperature to your preference. The rotary control is typically located on the shower valve and is designed to regulate the mix of hot and cold water. Before starting, ensure the water supply is turned on and the shower is in working condition. Begin by identifying the rotary temperature control knob, which is usually labeled with temperature indicators or color-coded for hot and cold. This knob is the primary mechanism for adjusting the water temperature.
To adjust the temperature, start by turning on the shower and letting the water run until it reaches a stable temperature. Then, locate the rotary control knob and rotate it slowly in the direction indicated for hotter or colder water. Turning the knob clockwise typically increases the temperature, while counterclockwise decreases it. Make small adjustments and test the water temperature after each turn to avoid sudden changes. If the knob has a limit stop, you may need to release it by pulling the knob outward before making adjustments, then re-engaging it once the desired temperature is set.
For more precise control, some Globe Union models feature a temperature limit stop that prevents the water from becoming too hot, which is especially useful for preventing scalding. To adjust this limit, locate the set screw or release button on the side or top of the rotary knob. Use a screwdriver or press the button to disengage the limit stop, then rotate the knob to the desired maximum temperature. Re-engage the limit stop to secure the setting. This ensures the water temperature remains within a safe and comfortable range.
If the rotary control feels stiff or difficult to turn, it may be due to mineral buildup or lack of use. In such cases, apply a small amount of silicone-based lubricant to the knob’s mechanism to ensure smooth operation. Avoid using oil-based lubricants, as they can degrade the rubber components over time. Regularly cleaning the knob and surrounding area can also prevent debris from interfering with its function.
Finally, after adjusting the rotary temperature control, test the shower again to ensure the water temperature is consistent and meets your needs. If the temperature fluctuates or the adjustment doesn’t hold, check for any loose components or consult the Globe Union user manual for model-specific troubleshooting tips. Properly adjusting the rotary temperature control not only enhances your shower experience but also ensures safety and efficiency in water usage.
Quick Guide: Turning Off Cold Water Supply to Your Shower
You may want to see also
Explore related products
Check for Scald Prevention Settings
When adjusting the water temperature on your Globe Union tub shower, it's crucial to check for scald prevention settings to ensure safe and comfortable use. Many modern shower valves, including those from Globe Union, come equipped with built-in scald prevention mechanisms to limit the maximum water temperature and prevent accidental burns. Start by locating the temperature limit stop, which is typically found on the shower valve cartridge or behind the handle. This stop is often a small screw or tab that restricts how far you can turn the handle toward the hot water side. Use a screwdriver to adjust this stop if needed, but be cautious not to remove it entirely, as this could eliminate the scald protection feature.
Next, test the water temperature after identifying the scald prevention setting. Turn on the shower and let the water run until it reaches its maximum temperature. Use a thermometer to measure the water temperature at the showerhead. Most scald prevention settings are designed to limit the water temperature to around 120°F (49°C), which is considered safe for most users. If the temperature exceeds this, you may need to further adjust the limit stop or consult the user manual for specific instructions on recalibrating the scald prevention feature.
If your Globe Union tub shower does not have an adjustable limit stop, check for a non-removable scald guard within the valve cartridge. Some models incorporate a fixed scald prevention mechanism that cannot be adjusted by the user. In such cases, ensure the valve is installed correctly and functioning as intended. If you suspect the scald guard is malfunctioning, contact a professional plumber to inspect and replace the valve if necessary.
For added safety, consider installing a thermostatic mixing valve if your Globe Union shower does not already have one. Thermostatic valves automatically regulate water temperature, providing consistent and safe output while preventing sudden temperature spikes. These valves are particularly useful in households with children or elderly individuals who are more susceptible to scalding.
Finally, regularly inspect and maintain the scald prevention settings to ensure they remain effective. Over time, mineral buildup or wear can affect the valve's performance. Periodically clean the shower valve and test the water temperature to confirm the scald prevention mechanism is functioning correctly. By prioritizing these checks, you can maintain a safe and comfortable shower experience while maximizing the longevity of your Globe Union tub shower system.
Easy Guide to Installing Water Supply for Your Shower Stall
You may want to see also
Explore related products
Test Water Temperature Range
To test the water temperature range on your Globe Union tub shower, start by ensuring the shower is properly installed and functioning. Turn on the water supply and let the water run for a few minutes to stabilize the temperature. Begin by setting the handle to its middle position, which typically balances hot and cold water. Gradually adjust the handle in both directions to observe the temperature changes. Pay close attention to how the water feels on your skin or use a thermometer for precise measurements. This initial test helps you understand the baseline temperature range and identify any extreme fluctuations.
Next, focus on testing the maximum hot water temperature. Turn the handle fully toward the hot water side and let the water run for at least 30 seconds. Use a thermometer to measure the temperature, ensuring it does not exceed 120°F (49°C) to prevent scalding. If the water is too hot, you may need to adjust the temperature limit stop inside the valve, as outlined in the Globe Union instructions. This step is crucial for safety, especially in households with children or elderly individuals.
Proceed to test the minimum cold water temperature by turning the handle fully toward the cold water side. Allow the water to run for 30 seconds and measure the temperature. Ideally, the water should feel cool but not uncomfortably cold. If the cold water is not flowing properly or the temperature seems inconsistent, check for any blockages in the cold water supply line or valve. Ensuring a balanced cold water flow is essential for achieving the desired temperature range.
To further refine the temperature range, perform a mixed water test. Set the handle to a position where both hot and cold water are mixed, aiming for a comfortable shower temperature, typically around 100°F to 110°F (38°C to 43°C). Use a thermometer to verify the temperature and adjust the handle slightly until you achieve the desired warmth. This test ensures that the shower can consistently deliver a safe and comfortable water temperature for daily use.
Finally, repeat the temperature tests after making any adjustments to the valve’s temperature limit stop or handle positioning. Consistency is key, so ensure the water temperature remains stable across multiple tests. If you encounter persistent issues, such as uneven temperature control or inadequate water flow, consult the Globe Union user manual or contact a professional plumber for further assistance. Properly testing and adjusting the water temperature range ensures a safe and enjoyable shower experience.
Average Shower Water Usage: How Many Inches Per Hour?
You may want to see also
Explore related products
Troubleshoot Temperature Fluctuations
Temperature fluctuations in your Globe Union tub shower can be frustrating, but they are often caused by common issues that can be resolved with a few troubleshooting steps. Start by checking the shower valve cartridge, as wear and tear on this component is a frequent culprit. Over time, mineral deposits or debris can accumulate, causing the cartridge to malfunction and disrupt water temperature control. To inspect the cartridge, turn off the water supply, remove the handle, and carefully extract the cartridge. Clean it thoroughly with vinegar or a descaling solution, and if it’s damaged, replace it with a compatible Globe Union cartridge.
Another potential cause of temperature fluctuations is improper balancing between hot and cold water lines. Globe Union tub showers often have a pressure balance valve designed to maintain a consistent temperature, but this can fail if the lines are not properly calibrated. To address this, adjust the temperature limit stop on the valve cartridge by turning the adjustment screw clockwise to reduce maximum hot water or counterclockwise to increase it. Test the water temperature after each adjustment to ensure it remains stable. If the issue persists, consider installing a new pressure balance valve to restore proper functionality.
Water pressure imbalances can also lead to temperature fluctuations. If the hot water supply has significantly lower pressure than the cold water, the shower may suddenly turn cold when another fixture is used elsewhere in the house. To troubleshoot this, check the water pressure at both the hot and cold supply lines using a pressure gauge. If an imbalance is detected, inspect the shut-off valves for clogs or partial closures and clean or replace them as needed. Additionally, ensure the water heater is functioning correctly and set to an appropriate temperature (typically 120°F) to prevent scalding and maintain consistent output.
Finally, sediment buildup in the showerhead or valve can restrict water flow and cause temperature inconsistencies. Remove the showerhead and soak it in a vinegar solution to dissolve mineral deposits. Flush the valve by running hot and cold water separately to clear any debris. If the problem continues, disassemble the valve and clean all internal components. Regular maintenance, such as periodic cleaning and inspections, can prevent sediment-related issues and ensure your Globe Union tub shower operates smoothly.
By systematically addressing these common issues—cartridge wear, temperature balancing, water pressure, and sediment buildup—you can effectively troubleshoot and resolve temperature fluctuations in your Globe Union tub shower. Always refer to the manufacturer’s instructions or consult a professional if you’re unsure about any step to ensure safe and accurate repairs.
Prevent Tub Water Splashes: Easy Tips for a Dry Shower Experience
You may want to see also
Frequently asked questions
Locate the temperature limit stop on the faucet handle, typically a screw or stopper underneath the handle. Use a screwdriver to adjust it clockwise to decrease the maximum hot water temperature or counterclockwise to increase it.
The issue may be due to the temperature limit stop being set incorrectly or the cartridge needing adjustment. Check the limit stop and adjust it as needed, or replace the cartridge if it’s worn out.
Yes, most Globe Union tub showers have a balancing valve or cartridge that controls the mix of hot and cold water. Adjust the valve or replace the cartridge if the balance is off, following the manufacturer’s instructions.
